| Capacity | 30KVA/30KW |
| Battery Type | Lead Acid |
| Power Factor | 1.0 |
| Waveform | sinewave |
| Protection | Overload, Discharge |
| AC / DC efficiency | <94% |
| Input Voltage Range | 304 to 456 |
| Recharge Time to 90% | 4 hours |
| Input connector | Hard wire |
| Backup time at full load | 7min |
| Transfer time | 0 ms |
| Output Type / Number | Hard wire |
| Voltage | 380Vca |
| Design technology | Online Double Convertion |
| Phase | Three-Phase |
| Current Crest | 3:1 |
| Harmonic distortion | </=2% THD (cargas lineales) </=4% THD (cargas no lineales) |
| Frequency | 50/60Hz Autosensing |
| Interface (Ports of communication) | USB and SERIAL |
| Software | Software |
| Certifications | ISO9001, ISO14001, CIDET, CE, ENERGY STAR, UL1778 Y FCC |
| Output Voltage regulation | +/-1% en modo bateria |
| Indicators Type | LCD |
| Backup time at half load | 12 min |
| Capacity Range | 10 -30KW |
| UPS Topology | Online Double Convertion |
| VA Capacity | 30KVA/30KW |
| Battery Technology | Sealed lead acid |
