| Capacity | 250KVA/225KW |
| Battery Type | Lead Acid |
| Power Factor | 0.9 |
| Waveform | sinewave |
| Protection | Overload, Discharge, 20KA surge suppressor included, Immunity to phase rotation, double redundant power supply. |
| AC / DC efficiency | Greater than 92% |
| Input Voltage Range | +/- 25% |
| Recharge Time to 90% | 4 Hrs |
| Input connector | Hardwire |
| Backup time at full load | 5 minutes |
| Transfer time | 0 ms |
| Output Type / Number | Hardwire |
| Voltage | 208 Vac |
| Design technology | Online Double Convertion |
| Phase | Three-Phase |
| Current Crest | 3:1 |
| Harmonic distortion | <2% Linear loads, <5% non-linear loads |
| Protection from voltage spikes | 20KA surge suppressor |
| Frequency | 50/60Hz Autosensing |
| Interface (Ports of communication) | RS232, SNMP Optional |
| Type / Quantity of batteries | 32 X 150Ah (no Included) |
| Output Voltage regulation | +/- 1% for balanced load and +/- 5% for unbalanced load |
| Indicators Type | LCD |
| Capacity Range | 10 -225KW |
| Wh Capacity | 57600 |
| UPS Topology | Online Double Convertion |
| VA Capacity | 250KVA/225KW |
| Battery Technology | Sealed lead acid |
