| Capacity | 10KVA/10KW |
| Battery Type | Lead Acid |
| Power Factor | 1.0 |
| Waveform | sinewave |
| Protection | Overload, Short circuit, Autorun, surge protect, EMI, RFI. |
| AC / DC efficiency | 0% |
| Input Voltage Range | 110-300vca |
| Recharge Time to 90% | 4hrs |
| Input connector | Hardwire |
| Backup time at full load | 5min |
| Transfer time | 0 ms |
| Output Type / Number | Hard wire |
| Voltage | 208 Vac |
| Design technology | Online Double Convertion |
| Phase | Split-Phase |
| Current Crest | 3:1 |
| Harmonic distortion | </=3THD |
| Protection from voltage spikes | 660 Joules |
| Frequency | 50/60Hz (auto-sensing) |
| Interface (Ports of communication) | USB / Serial |
| Accessories | Cable USB/Manual/Software |
| Type / Quantity of batteries | 20 pcs 12vcd 9 Ah |
| Cabinet with batteries (LxHxD)mm | (250x830x610)mm |
| Software | Viewpower |
| Certifications | TUV,UL,Rohs. |
| Output Voltage regulation | 208 +/- 1% |
| Indicators Type | LCD |
| Backup time at half load | 10min |
| Capacity Range | 10 -10KW |
| Wh Capacity | 2160 |
| UPS Topology | Online Double Convertion |
| VA Capacity | 10KVA/10KW |
| Battery Technology | Sealed lead acid |
| Form Factor | tower |
